Scott Roxter 20

Scott Roxter 20
  • Color: Green
  • Color: Silver
$649.99
Color:
Size: 20-inch
Please select options Unavailable

Details

The SCOTT Roxter 20 will just make you want to get out and ride. Finish your homework, kids, the trails are calling!

KEY FEATURES
- Kids from 115 cm
- 20'' wheels
- 10.3 kg / 22.71 LBS
- Versatile bike for trails and city
- Big tires to bring more comfort
- Equipped with 8 gears
- Bigger cassette to easier climbs

Geometry
Geometry Chart:
20"
A HEAD TUBE ANGLE 69.0 °
B HEAD TUBE LENGTH 110.0 MM
C TOP TUBE HORIZONTAL 465.0 MM
D STANDOVER HEIGHT 510.9 MM
E BB OFFSET
F BB HEIGHT 0.0 MM
G WHEEL BASE 889.6 MM
H BB CENTER TO TOPTUBE CENTER
I BB CENTER TO TOP OF SEATTUBE 280.0 MM
J SEAT ANGLE 66.7 °
K CHAINSTAY 370.0 MM
L REACH
M STACK
N STEM LENGTH 50.0 MM
0 TRAIL

Specs

Pedals MARWI SP-700 / w/Reflector
Fork AL-6061 rigid fork / IS / PLUS
Hubs Formula DC-19-F / QR|Formula DC-25-8-R / QR
Rims Shining MP-32 Disc
Stem LEADTEC LCS-7130, 50mm / 25.4mm clamp
Chain KMC Z8.3
Frame Roxter 20 PLUS Junior, Alloy 6061 / Semi int. HT, SCOTT dropout / IS
Tires Kenda K1080 SlantSix / 20x2.6" / 30TPI
Brakes Tektro SCM-02, Mech. Disc Brake / 160mm rotor
Saddle Syncros Youth
Spokes 15G / UCP / black
Headset Feimin FP-H807, 1 1/8" Semi Int.
Crankset Prowheel / Alloy Crank 127mm, 36T / w/CG PVG double cover
Seatpost Alloy / 26.8mm / 250mm
Shifters Shimano SL-RS45-8R, Revo Shifter
Handlebars Junior Flat-Bar / Alloy, 560mm / Syncros Youth 100/80 Grip
Brake Levers Tektro JL-510 TS / RS
Bottom Bracket Feimin / BB68 / cartridge / square taper
Rear Derailleur Shimano RD-TX800 Tourney, 8 Speed
Accessories & Extras Kickstand Syncros Stem Protector
Cassette/Freewheel SunRace CSM55, 8 Speed / 11-34T

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Green / 20-inch 192820757735 290753222 29021345153S
Silver / 20-inch 192820758053 290769222 29024729280S
